The quick façade repair for two-leaf cavity walls

Remedial wall tie mechanical VBS-M

Name: Remedial wall tie mechanical VBS-M
Brand: fischer

The fischer remedial wall tie VBS-M is suitable for the renovation of two-shell masonry. Above all, it is used for the subsequent application of heat insulation or to secure a suspended, rear-ventilated façade. Thanks to the two expansion zones of the plug, the cost-effective solution enables the safe connection of the facing masonry and outer shell. The low anchorage depth of just 50 mm also enables fast and cost-effective installation in stone and in bed joints. The slim plug edge and head enable a flush installation or a deeper installation with no annoying projection. The drill hole can be retrospectively grouted so that it is no longer visible.

Product variants

Download of image data

Product variants

14 Product variant (s)

Max. shell distance at 115 mm facing masonry, flush installation

Max. shell distance at 115 mm facing masonry, 20 mm sunk installation

Facing masonry + cavity

Drill diameter

Drill hole depth

Anchor length

Viewed 14 of 14 variant (s)

Advantages

The approved fixing in stone and in joints from at least 50 mm facing masonry provides a high degree of flexibility and security.
Use in joints and with a low anchorage depth of just 50 mm allows for a quick and economical installation.
The small anchor rim and screw head allow for a surface-flush or deep-set installation.
The drill hole can be retrospectively sealed so that it is no longer visible in the façade.
A drip coil prevents condensate running into the load-bearing layer, thus preventing frost and corrosive damage.

Functioning

The remedial wall tie VBS-M is set in the load-bearing layer and into facing masonry using push-through installation.
In accordance with the approval, no drill hole cleaning is required.
The two expansion zones in the load-bearing layer and in the facing masonry ensure a secure fixation.
The plug doesn't fix into the facing masonry until the head grips into the load-bearing layer. This ensures the very best installation safety.

Mounting Strip 1 Picture

1 / 4

System components

Max. shell distance at 115 mm facing masonry, flush installation	20 mm
Max. shell distance at 115 mm facing masonry, 20 mm sunk installation	—
Facing masonry + cavity ( t_fix )	70 mm
Drill diameter ( d₀ )	8 mm
Drill hole depth ( h₀ )	140 mm
Anchor length ( l )	120 mm
Effect. anchoring depth ( h_nom )	> 50 mm
Packaging	Folding box
Amount	100 St.
GTIN (EAN-Code)	4048962131642

Max. shell distance at 115 mm facing masonry, flush installation	20 mm
Max. shell distance at 115 mm facing masonry, 20 mm sunk installation	40 mm
Facing masonry + cavity ( t_fix )	135 mm
Drill diameter ( d₀ )	8 mm
Drill hole depth ( h₀ )	205 mm
Anchor length ( l )	185 mm
Effect. anchoring depth ( h_nom )	> 50 mm
Packaging	Folding box
Amount	100 St.
GTIN (EAN-Code)	4048962131659

Max. shell distance at 115 mm facing masonry, flush installation	40 mm
Max. shell distance at 115 mm facing masonry, 20 mm sunk installation	60 mm
Facing masonry + cavity ( t_fix )	155 mm
Drill diameter ( d₀ )	8 mm
Drill hole depth ( h₀ )	225 mm
Anchor length ( l )	205 mm
Effect. anchoring depth ( h_nom )	> 50 mm
Packaging	Folding box
Amount	100 St.
GTIN (EAN-Code)	4048962131666

Max. shell distance at 115 mm facing masonry, flush installation	60 mm
Max. shell distance at 115 mm facing masonry, 20 mm sunk installation	80 mm
Facing masonry + cavity ( t_fix )	175 mm
Drill diameter ( d₀ )	8 mm
Drill hole depth ( h₀ )	245 mm
Anchor length ( l )	225 mm
Effect. anchoring depth ( h_nom )	> 50 mm
Packaging	Folding box
Amount	100 St.
GTIN (EAN-Code)	4048962131673

Max. shell distance at 115 mm facing masonry, flush installation	80 mm
Max. shell distance at 115 mm facing masonry, 20 mm sunk installation	100 mm
Facing masonry + cavity ( t_fix )	195 mm
Drill diameter ( d₀ )	8 mm
Drill hole depth ( h₀ )	265 mm
Anchor length ( l )	245 mm
Effect. anchoring depth ( h_nom )	> 50 mm
Packaging	Folding box
Amount	100 St.
GTIN (EAN-Code)	4048962131680
